Innovative lightweight constructionfor the mobility of tomorrow
CO2 emissions must be reduced - also in the automotive industry. To support auto manufacturers on the road to climate neutrality, our colleagues at thyssenkrupp Steel have set themselves the task of developing economical and safe lightweight solutions to reduce CO2. From design and production processes to the manufacture of innovative materials.
Cars without steel - it won't work
Steel is now the most successful lightweight material in the auto industry. Nine out of ten vehicles in Europe are currently manufactured using a lightweight design dominated by steel. The innovative material is also gaining ground in electrically powered vehicles. In the long term, the material can make a significant contribution to reducing CO2 emissions.
600 kg steel in one car
Steel is the core material of the automotive industry - even in the age of electromobility. Steel is used in drive motors and in the structures of current e-cars and plug-in hybrids. The structure of a current e-car, for example the VW ID.4, weighs around 440 kilograms including the battery box. Doors and flaps weigh another 120 kilograms or so. Since aluminum has no or only a very small weight advantage in the structure, steel is generally preferred here. In addition, all drive motors for electric vehicles require a larger quantity of electrical steel. Depending on the model and whether it is a purely electric car or a plug-in hybrid vehicle - each motor contains between 20 and 90 kilograms of electrical steel, which cannot be replaced by other materials. Thus, the car in our example calculation consists of more than 600 kilograms of steel - and that's just in the basic structure.
Dual-phase steel - lightweight and higher strength
Why steel, and above all lightweight steel, is a preferred material for auto manufacturers becomes clear when looking at CO2 emissions. Because unlike solutions made from aluminum, lightweight steel is significantly more sustainable and cost-effective.
Dual-phase steels can be used, for example, to produce very thin, lightweight and higher-strength body parts for cars. Significant weight reductions are possible by reducing the thickness. The dual-phase steel DP-K® 290Y490T from thyssenkrupp Steel, for example, makes it possible to produce an outer skin with a thickness of just 0.55 millimeters. A protective layer of hot-dip galvanizing or zinc-magnesium is included.
Hot forming
In addition, hot forming, as a leading manufacturing technology, offers significant potential for reducing both costs and weight in automotive production. Press-hardenable manganese-boron steels (MnB) are particularly well suited for safety-relevant structural components in vehicle bodies due to their high strength combined with good forming properties. Hot-formed body components such as the A-pillar, B-pillar, longitudinal and cross members, as well as the inner and outer door sills, meet the requirements for weight reduction while maintaining the same level of stiffness, high strength and good dimensional accuracy, as well as improved crash performance. The MBW-K® 1900 product in particular offers maximum potential for weight savings. This grade impresses with its high resistance to deformation in the event of a crash and is used in bumpers, side-impact beams and transversely loaded cross members.
Lower emissions thanks to lightweight steel
Although electric cars no longer emit any emissions, the production of an electric car does generate production-related emissions. It is therefore important to consider production-related environmental impact when selecting materials. And this is where new steel concepts for battery housing come out on top. Compared with aluminum-based solutions used today, they produce up to 50 percent less climate-damaging CO2 at significantly lower cost despite a slight increase in weight. In addition, steel is a very sustainable material that can be recycled while maintaining the same quality.
Clean mobility thanks to CO2-free steel
However, if the goal of green mobility is to be achieved in the future, it is of course also important for steel to become CO2-free. thyssenkrupp Steel has developed its own innovative technology for this and set itself ambitious targets. By 2030, CO₂ emissions from steel production are to be reduced significantly further. The long-term goal is to fundamentally transform steel production and gradually lower its CO₂ emissions. One key requirement for achieving this is a stable regulatory framework – not only here, but worldwide: in China, India, Russia and across the globe.
